- Introduction The original Power Probe 3 uses a 20ft cable which attaches to the vehicle’s battery, allowing the user to perform an electrical test anywhere in, or around the vehicle. The PP3 is a Voltmeter and Continuity Tester, with Audible & Visual indicators along with two LED headlights to light up your work area. This circuit tester also supplies Battery Voltage or Ground to activate components. This powerful time-saver tool is perfect for every level of technician. Features – DC Voltmeter Indicators provide active feedback – LED Lights – Bad Ground –Indicator – Short Circuit Indicator – Relay and Component Tester – Audible Monitoring of Electrical Signals https://www.rafdan.is/wp-content/uploads/2023/04/20211105115020935.mp4 Specifications – DC 0 – 70V 1 digit – P-P 0 – 70V Frequency response of tone pass through – 10Hz to greater than 10 Khz PP display – 15Hz Square Wave – 35Hz Sine Wave Power Probe Mode – Continuity to ground – First level – display is enabled less than 20K – Second level – green LED is enabled less than 2K – & Peak Detector Response – Single event capture less than 200μs pulse width – Repetitive events less than 1μs pulse width Peak to Peak Mode – 0 – 70V 1 digit – 4Hz to over 500kHz Square Wave input – 4Hz to over 250kHz Sine Wave input Threshold for PPAC/Audible passthrough Circuit Breaker 8 amp thermal response – Manual reset Typical Response User Manual Datasheet
